Explosion-proof LED Light for Hazardous Areas with IP66 Protection and 100-277VAC Wide Voltage Input

2
MOQ
50-150USD
Price
Explosion-proof LED Light for Hazardous Areas with IP66 Protection and 100-277VAC Wide Voltage Input
Features Gallery Product Description Chat Now
Features
Specifications
Name: Explosion-proof LED Light For Hazardous Areas With IP66 Protection And 100-277VAC Wide Voltage Input
Lamp Power: 30W,50W,60W
Colour Temperature: 5700K
Colour Rendering Index: >80
Rated Voltage: 100-277VAC,50/60Hz;220-240VAC 50/60Hz
Degree Of Protection: IP66
Cable Entries: G3/4"
Cuctomized: Available
Highlight:

Explosion-proof LED light IP66

,

Hazardous area lighting 100-277VAC

,

Explosion proof wide voltage LED

Basic Infomation
Place of Origin: CHINA
Brand Name: Cherubim
Certification: ATEX
Payment & Shipping Terms
Packaging Details: Carton
Delivery Time: 5-9DAYS
Payment Terms: L/C,T/T,Western Union
Supply Ability: 50000set/Month
Product Description
Explosion-proof LED Light for Hazardous Areas with IP66 Protection and 100-277VAC Wide Voltage Input
Typical Applications
  • Can be used in
  • Zone 1 and Zone 2
  • Zone 21 and Zone 22
  • Class l, Zone 1 and Zone 2
  • Class IIA, IIB, and IIC explosive gas environments
  • T1 - T6 temperature groups
  • Applicable lamp and power (max.100V)LED :50W,70W, 100,150w
  • Low-maintenance costs due to long service life
Technical Data
EX Mark Exde IIC T6 Gb / Ex tD A21 T80℃
Enclosure Copper-free aluminium alloy, powder coated surface, yellow
Transparent cover Toughened glass, stands 4J impact
Exposed fastener Stainless steel
LED driver Wide voltage input,CC-CV (constant current - constant voltage) output
Lamp specification LED
Lamp power (W) 30W,50W,60W
Colour rendering index (Ra) >80
Colour temperature (CCT) 5700K Note: cool white is available in general
Rated voltage 100-277VAC,50/60Hz;220-240VAC 50/60Hz
Degree of protection IP66
Mounting Ceiling type, wall type, bracket type
Cable entries G3/4"
Available cable outer diameter Φ10mm-Φ14mm
Features
1 Zone 2, Zone 21&22.

2 Instant on crisp white light output.

3 High efficiency drivers and LEDs provide, low cost operation in harsh and heavy industrial applications.

4 Isolated LED compartment reduces temperature within driver housing.

5 Multi choice of beam angle for 60° 90° 120°.

6 LED lifetime:100000hrs.
FAQ:






1. How can we guarantee quality?
Always a pre-production sample before mass production.
Always final Inspection before shipment.

2.Do you have any MOQ limit for light order?
MOQ, 1pc for sample checking is available.

3. Can you accept put my logo on light product?
Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

4.What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW.
Accepted Payment Currency: USD,GBP,CNY.
Accepted Payment Type: T/T,L/C.
Language Spoken: English,Chinese

5.Warranty
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%. Secondly,
during the guarantee period, we will send new lights with new order for small quantity. All products have been tested before the shipment and it was packaged in good condition.For defective batch products,
Please tested the products at first before you assemble it, if any problem here, please inform us within 3 days of receipt. We can arrange the replacement for you if the situation is confirmed.
